SUBSEA CAMERAS

InspecamCorder


Subsea battery powered camcorder at 2 MP (Optional 8 MP) for live streaming without umbilical. Designed for ROV and  marine inspections for up to 24 hours operation.

  • 2 MP Camcorder, option 8 MP
  • Up to 24 hours operation
  • Rated depth 3000 m  (optional 6000 m)

Inspecam ® HD-IP

  • Benefits:
  • 5 MP
  • Reliable and stable software for operation from any pc.
  • 500 or  4000 m depth. (optional 6000 m)


Subsea network 5 MP camera and live images can be monitored at 30 fps. Dual streaming for transmission of images with different angles of view.  Up to 5 users can view images from one camera at the same time. Date & time can be superimposed on images.  PoE compliant.

Inspecam ® HD-IPLX


Subsea network camera with powerful light source, for monitoring live images at 30 fps. Dual streaming for transmission of images with different angles of view.  Up to 5 users can view images from one camera at the same time. Date & time can be superimposed on images.  PoE compliant.

  • Benefits:
  • IP Camera with powerful light source.
  • HD quality over internet anywhere.
  • Easy operation from any pc.
  • Integrated powerful light source.

Inspecam ® DW HD


High performance mini camera for general applications, with detachable front sleeve for inspections up to 6000 m depth.

  • Benefits:
  • Compact.
  • Detachable front sleeve for maintenance.
  •  SD / 2 MPixels / 5 Mpixels

Inspecam ® Diver HD


All-around subsea camera for general use as towed, technical diving, etc.  Available also made of stainless steel / titanium housing. The minimum object distance can be pre-adjusted. With bulkhead connector or inline with 0.5 m cable connector.

  • Benefits:
  • Available formats:  4:3   700 TVL     16:9  HD 2 MP
  • Compact and light.
  • Supply fra 9 to 24 V
  • Affordable.

Inspecam ® LX HD


Subsea camera with 10 Watt light source. Designet primary for confined spaces, where there is no space for an external light source. Rated depth: 500 m.

Inspecam ® Z


High performance subsea camera, for applications at 4000 or 6000 meters depth.

  • Benefits:
  • 18x optical zoom
  • Control from keyboard w/VISCA protocol
  • Sony software for pc control

Inspecam ® HDZ-A/HDZ-IP


HD IP Zoom camera for applications at 300, 4000 or 6000 meters depth.

  • Benefits:
  • 10-20x optical zoom
  • Control from keyboard w/VISCA protocol (Analogue)
  • Control from any pc (IP type)

Inspecam ® PTA / PT IP


Pan & Tilt Zoom subsea camera. Free 360° rotation, manual or autofocus and  other editable functions from OSD menu.

  • Benefits:
  • Easy controlled by joystik or over internet
  • Easy operation from any pc
  • 500 or 2000 m rating depth
  • Optical borosilicate BK7 glass dome
